Narrow modular coverage suits complex roof geometry
InquiryModular Roofing Product
Modular Insulated Aluminum Panel (365 mm Width)
Compact modular coverage for flexible installation
A compact modular insulated roofing material that is easier to position around detailed roof geometry, smaller roof sections, edges, extensions, and covered circulation areas.
- Overall depth
- 35 mm
- Effective width
- 333 mm
- Overall width
- 365 mm
- Fire rating
- B1
Catalogue specification
Panel profile, dimensions, and construction
The complete catalogue figure is shown without cropping so buyers can review the cross-section, coverage, construction, features, and typical applications together.
- Overall depth
- 35 mm
- Effective width
- 333 mm
- Overall width
- 365 mm
- Aluminum skins
- 3xxx-series aluminum skins
- Insulation core
- Polyurethane insulation made with BASF raw materials
- Fire rating
- B1
- Aluminum skin thickness
- 0.3-1.2 mm
- Panel length
- Cut to project requirements, subject to handling, loading, and transport feasibility
Material construction
Aluminum skins with a polyurethane insulation core
The narrower 333 mm effective width supports flexible setting-out and handling where broad large-format panels may be less practical. Reinforced ribs help preserve surface stability while custom lengths reduce unnecessary on-site trimming.
The 3xxx-series aluminum skins provide a corrosion-resistant exterior, while polyurethane insulation made with BASF raw materials supports thermal and acoustic separation. Aluminum skin thickness can be customized from 0.3-1.2 mm.
Buyer benefits
Performance that matters in roof selection
Lightweight sections are practical to position and install
Reinforced panel construction maintains rigidity
Custom project lengths help reduce site waste
Applications
Where 365 mm modular panel fits
Final selection should be coordinated with roof geometry, structure, climate, insulation priority, appearance, drainage, handling, and installation planning.
Small factory and workshop roofs
Residential extensions
Custom homes and rural residences
Covered walkways and canopies
Customization and ordering
Commercial information for procurement planning
No generic price is published because specifications, quantity, packing, destination, and trade terms change the final quotation.
- MOQ and samples
- 500 linear meters per product; small-quantity samples are available.
- Lead time
- Within 3 working days for samples; typically 7-15 working days for bulk orders.
- Customization
- 0.3-1.2 mm aluminum skins; ral color codes or customer-supplied physical color samples; cut to project requirements, subject to handling, loading, and transport feasibility.
- Packing
- Protective surface film with cushioning during container loading. Additional packing details can be agreed with the buyer.
- Inspection
- Live video-call inspection before shipment; additional arrangements negotiable
- Trade terms
- EXW is preferred; FOB is negotiable.
- Payment
- Confirmed in the sales contract
Warranty support
GMiSU provides warranty support for manufacturing-related quality issues under normal use and proper installation. Damage caused by improper handling, misuse, unauthorized modification, incorrect installation or other human factors is excluded. The applicable scope of warranty support will be confirmed according to each project and order agreement.
Quality documentation
Review quality assurance Reports and technical documents available on request
Complete test reports and additional technical documents are available upon request. The complete five-page B1 fire-performance report is also displayed inline on the homepage.
Related roofing products
Compare the remaining panel profiles
45 mm / 950 mm effective width
45 mm Large-Format Insulated Aluminum Panel
Balanced insulation and rigidity for versatile roofing projects
View product65 mm / 950 mm effective width
65 mm Large-Format Insulated Aluminum Panel
Enhanced insulation for demanding roofing applications
View product
33 mm / 1,000 mm effective width
33 mm Flat Insulated Aluminum Panel
A clean flat profile for contemporary architectural projects
View productQuestions about 365 mm Modular Panel
What is the minimum order quantity?
The MOQ is 500 linear meters per product. Small-quantity samples can be ordered before bulk production, while final bulk arrangements are confirmed for each project.
Which parts of the panel can be customized?
Colors, aluminum skin thickness from 0.3-1.2 mm, panel length, and project coordination details can be customized. Colors can follow RAL codes or a customer-supplied physical sample.
How quickly can GMiSU prepare samples and bulk orders?
Samples can normally be prepared within 3 working days. Typical bulk production lead time is 7-15 working days after order details are confirmed.
How can buyers inspect an order before shipment?
A live video-call inspection can be arranged before shipment. Additional inspection methods can be discussed and recorded in the order agreement.
- MOQ
- 500 linear meters per product
- Samples
- Small-quantity samples are available
- Sample lead time
- Within 3 working days
- Bulk lead time
- Typically 7-15 working days
- Response
- Within 12 hours
Start your project
Tell us what you need to build.
Share your product type, dimensions, color, quantity, drawings, destination market, and target schedule with Levi Leung.
